| Technical Specs |
| Frequency Range (MHz) |
600 - 6500 |
| Polarization |
Vertical or Horizontal |
| Gain (dBi) |
15 Low/ 20 Mid/ 25 High |
|
Half-power Beam Width (0)
|
Low Band: 20 H, 23 V I Mid Band: 12 H, 15 V
|
| H Front-to-back Ratio (dB) |
20 AVG |
| Impedance (0) |
50 |
| VSWR |
1.6:1/ 1.4:1 AVG |
| Max Input Power (W) |
100 |
| Lighting Protection |
DC Ground |
| Connector |
N- Female |
| Dimensions (mm) |
60x99x40 |
| Dimensions, Boxed (mm) |
51x63x10 |
| Antenna Weight (kg) |
2.4 with bracket |
| Packing Weight (kg) |
3.3 |
| Rated Wind Velocity (kph) |
209 |
| Wind Load @ Rated Velo (M/ K) |
150/ 68 |
| Mounting Mast Diam. (in/ mm) |
1.5-2.0/ 40-50 |
| Reflector Material |
Aluminium |
| Reflector Finish |
Electrostatic Powder Coat |
| Radome Material |
ASA Anti UV |
| Antenna System Colour |
Flat Grey |
| Water Resistance |
IPX Weather Rated |
|
Operating Temperature (0C)
|
-40 to +60 |
