Features:
3.7" colour LED screen
Built in speaker for sound
High Definition on both satellite and antenna
MPEG2/Mpeg4 Compliant
MER,BER,C/N,dB Microvolts
3000mAH Lithium ION battery - Long lasting battery
HDMI output to view on bigger displays
AV Input for aligning security cameras
AV output
12V Power output for power CCTV cameras (there is a limit to the current output)
Can be used as a compact TV if you add a TV Antenna
Antenna power for powering mast head Amps
Backlit menu buttons
Built in torch - ideal when in the roof
Multimedia functions via the built in USB port
Power
Battery: 8.4v 3000mAH Lithium Ion
Consumption: 10w Max
Meter Input: 12V 1.5amp (2.1mm DC Jack)
Charger Input: 100-240Volt AC 50-60Hz
CCTV Power Output: 12V 100mA (Selectable on/off)
Antenna Power Output: 5Volt (Max 200mA), 12Volt (Max 100mA), 17Volt (Max 200mA) Selectable
Physical
Dimensions: 210 x 125 x 48mm
Weight: 660 Grams
Connections
1 x HDMI Output (V1.3)
1 x 12V DC CCTV Output
1 x 3.5 mm AV Input
1 x 3.5 mm AV Output
1 x USB 2.0
1 x 2.1 mm 12V DC Input
Full manual can be found at http://www.satking.com.au/publications/sku-9627-manual.pdf
